Product Overview

The machine line integrates a high‑speed forming unit with a precision finishing station, delivering continuous zipper tape production that meets the essential safety and performance criteria of the CE mark. Each module is engineered for repeatable dimensional control, reducing material waste and downstream rework.

A modular frame allows the forming head and the finishing head to be configured independently, so the same platform can serve both metal‑tooth and coil‑type zipper profiles. The control system uses a PLC with closed‑loop servo drives, providing real‑time feedback on pitch, tooth height, and tape tension.

Technical Specifications

Key Features

• Servo‑driven forming rollers maintain tooth geometry within ±0.02 mm across the full production run.
• Integrated infrared heating zone provides uniform finishing without hot‑spot formation.
• Automatic tension compensation adapts to variations in raw‑tape thickness, preventing slippage.
• Quick‑change tooling cartridges reduce changeover time to under 15 minutes.
• Built‑in data logger records critical process parameters for traceability and CE documentation.

Applications

The equipment is suited for manufacturers of garment zippers, luggage closures, and technical textiles where consistent tooth engagement and surface finish are critical. Because the finishing station can apply heat‑set or coating processes in‑line, it eliminates a separate post‑processing step, shortening lead times for high‑mix, low‑volume orders.

In automotive interior trim, the machine’s precise pitch control meets the tight tolerances required for seat‑belt and airbag zipper components. For outdoor gear, the adjustable temperature profile accommodates thermoplastic polyurethane (TPU) tapes that demand higher finishing temperatures.

Quality Control & CE Certification

Every unit undergoes a factory acceptance test (FAT) that verifies dimensional accuracy, electrical safety per EN 60204‑1, and mechanical guarding compliance with the Machinery Directive 2006/42/EC. The CE declaration of conformity is issued after the FAT and is supplied with the shipment documentation.

In‑process inspection points include laser‑based tooth height measurement, thermocouple verification of finishing temperature, and vibration analysis of the forming drive. Records are stored in the PLC historian and can be exported for customer audit.

Customization Options

• Alternative forming head geometries for specialty zipper profiles (e.g., invisible, waterproof).
• Additional coating stations (silicone, PTFE) integrated downstream of the finishing zone.
• Extended safety enclosure with light‑curtain interlocks for high‑speed lines.
• Remote monitoring package with OPC‑UA connectivity for Industry 4.0 integration.

Packaging & Shipping

Machines are shipped on fumigated wooden crates with shock‑absorbing foam inserts, compliant with ISPM‑15. Each crate includes a moisture‑barrier bag and desiccant packs to protect electronics during sea freight. Optional air‑freight packaging reduces crate dimensions for faster delivery.

Frequently Asked Questions

Can the machine dimensions be customized to fit an existing production line?

Yes. The frame length and height can be adjusted within a 200 mm envelope to match conveyor heights and space constraints. Detailed layout drawings are provided during the quotation phase.

What information is required before a formal quotation?

We need the target zipper profile (tooth type, pitch, tape material), desired output speed, available utility supplies (voltage, compressed air), and any local regulatory requirements beyond CE.

Which tape materials are compatible?

The system processes polyester, nylon, cotton, and TPU tapes ranging from 0.15 mm to 0.35 mm thickness. Compatibility with other substrates can be confirmed by a trial run.

How is quality inspected before shipment?

A full FAT is performed, covering dimensional checks, electrical safety tests, and a 30‑minute continuous run at rated speed. Test reports and the CE declaration accompany the equipment.

What packaging methods are available for export?

Standard wooden crates (ISPM‑15), optional vacuum‑sealed crates for humid climates, and air‑freight optimized packaging are offered. All options include shock indicators.

What is the typical production lead time?

Standard configurations ship within 10‑12 weeks after order confirmation. Custom tooling or additional stations may extend lead time to 14‑16 weeks.

How are samples arranged for evaluation?

We can produce a short pilot run (up to 200 m) at our test facility and ship the finished zipper tape for your quality review. Sample costs are credited against a subsequent purchase order.

Request a Quote

Provide your project specifications and we will return a detailed proposal including layout drawings, cycle‑time estimates, and a compliance checklist.

You may also download the CE declaration template or schedule a virtual factory tour to discuss integration details.
